Vibration motor generates a strong centrifugal force vibration by rotation of eccentric weights at both ends of rotor shaft.
With its strong vibration, the vibration motor is widely used for preventing the blockage or adhesion in the powder container (e.g., hoper and tank), and for equipment for filling, conveyance, and screening.
An appropriate item can be selected depending on the intended use, from a wide range of models.
Operable at 100V household commercial power supply
With single-phase 100VAC, the product can be installed easily for preventing the blockage in the tank, hopper, and chute for powder, and improving the clogging of product in the production line.
Adoption of water-resistant structure
Having a totally-enclosed drip-proof structure equivalent of IP code 66, the product can be used safely outdoors.
Display of IP code
IP (International Protection code) means Ingress Protection of electric equipment and cabinet for solid foreign object and water defined in the IEC standards 529.
IP6 (first code) 6 (second code)
The first code 6 means the protection for human body and solid foreign object.
The degree of protection is no internal ingress of dust.
The second code 6 means the protection against ingress of water.
The degree of protection is that no harmful influence is exerted from ocean waves or direct jet flow of water from any direction.
Support for fall prevention wire
The vibration motor comes standard with the attaching portion for fall prevention wire to prevent the vibration motor from falling if a mounting bolt is removed or the mounting portion is damaged.
*A wire is optional.
Easy adjustment of centrifugal force and amplitude
The centrifugal force can be adjusted by controlling the angle of adjustment weights of weights (fan eccentric weights) mounted on the right and left of vibration motor. The amplitude can be also adjusted.
These adjustments are made depending on the shape and weight of an object to which the vibration motor is installed.These adjustments are made depending on the shape and weight of an object to which the vibration motor is installed.
The inner blue sections show the fixed weights. The outer green sections show the adjustment weights.
Note) The right and left adjustment weighs must be slid in the same direction (as shown in the figure) to achieve a balance.
Usable in wide applications where vibration is adapted
The vibration motor is generally used for preventing the blockage of powder. Furthermore, it can be installed the equipment that requires vibration in vibration separation (Screen), vibration conveyance (Feeder), and vibration compaction (Table vibrator) by applying the usage.
